25HP semi-hermetic Refrigeration Condensing Units low temperature condenser Unit 6H-25.2-40P

Model Number : 6H-25.2

Certification : CE

Place of Origin : China

MOQ : 1pcs

Price : discussed

Payment Terms : T/T or western Union

Supply Ability : 3,000pcs per month

Delivery Time : 7-10 working days after received your payment

Packaging Details : Carton box

Product Name : condensing unit

type : semi-hermetic condensing unit

Horse power : 25HP

Cooling Method : Direct Cooling

Application : Cold room

Cool Type : Air-cooled

Color : Green

gross weight : 465kg

capacity : 317700W

Voltage : 380V/50Hz/3 phase-440v/60hz/3 phase

volume : 3.2CBM

liquid line : 22mm

suction line : 54mm

Contact Now

25HP Semi-Hermetic Refrigeration Condensing Units - Low Temperature Condenser Unit 6H-25.2-40P

Product Overview

25HP Low Temperature Condensing Unit 6H-25.2-40P for Cold Storage Room

Horse Power: 25HP

Voltage: 380V/50HZ/3Phase, 440-480V/60HZ/3PH

Ideal for cold rooms, fishing boats, and similar applications
Wide range of application capabilities
Original type designed specifically for low temperature operations

Product Specifications

Compressor condensing unit is widely used for different temperature ranges, applicable in cold storage, chiller rooms, freezer rooms, and similar environments.

Key Features

Equipped with semi-hermetic compressor for reliable quality
Open type condensing unit for easy installation and maintenance
Air-cooled cooling type
Suitable for wide temperature range: +5°C to -5°C (middle/high) and -15°C to -25°C (middle/low)
Copper tube and aluminum fin type heat exchanger
Compatible with refrigerants R404A and R22

Technical Specifications

Horse Power Range: 3-40HP

Voltage: 380V/50HZ/3Phase, 440-480V/60HZ/3PH

Performance Advantages

High efficiency, good reliability, low noise, low vibration, no leakage
Wide range of application with compatibility for R22, R134a, R404a, R407b, and R407c refrigerants
Excellent performance with scientific structure design and precision processing
Premium accessories including world-famous brands for filters, pressure controllers, oil separators, gas separators, and Harris high-quality welding rods
Reliable safety devices including motor protector and discharge temperature monitor
Available in both air-cooling and water-cooling condensing units

Available Models

Condensing Unit Models

New Model Number	Old Model Number	Horse Power
2HES-1	2HC-1.2	1HP
2HES-2	2HC-2.2	2HP
2GES-2	2GC-2.2	2HP
2FES-2	2FC-2.2	2HP
2FES-3	2FC-3.2	3HP
2EES-2	2EC-2.2	2HP
2EES-3	2EC-3.2	3HP
2DES-2	2DC-2.2	2HP
2DES-3	2DC-3.2	3HP
2CES-3	2CC-3.2	3HP
2CES-4	2CC-4.2	4HP
4FES-3	4FC-3.2	3HP
4FES-5	4FC-5.2	5HP
4EES-4	4EC-4.2	4HP
4EES-6	4EC-6.2	6HP
4DES-5	4DC-5.2	5HP
4DES-7	4DC-7.2	7HP
4CES-6	4CC-6.2	6HP
4CES-9	4CC-9.2	9HP
4VES-7	4VCS-6.2	6HP
4VES-10	4VCS-10.2	10HP
4TES-9	4TCS-8.2	8HP
4TES-12	4TCS-12.2	12HP
4PES-12	4PCS-10.2	10HP
4PES-15	4PCS-15.2	15HP
4NES-14	4NCS-12.2	12HP
4NES-20	4NCS-20.2	20HP
4JE-15	4J-13.2*	13HP
4JE-22	4J-22.2*	22HP
4HE-18	4H-15.2*	15HP
4HE-25	4H-25.2*	25HP
4GE-23	4G-20.2*	20HP
4GE-30	4G-30.2*	30HP
6JE-25	6J-22.2*	20HP
6JE-33	6J-33.2*	33HP
6HE-28	6H-25.2*	25HP
6HE-35	6H-35.2*	35HP
6GE-34	6G-30.2*	30HP
6GE-40	6G-40.2*	40HP
6FE-44	6F-40.2*	40HP
6FE-50	6F-50.2*	50HP

Technical Specifications Table

Model	Horse Power	Displacement (50hz) m³/h	Quantity of Cylinder * Diameter * Stroke (mm)
2DC-2.2	2	13.5	25039.3
2DC-3.2	3	13.5	25039.3
2CC-3.2	3	16.2	25539.3
2CC-4.2	4	16.2	25539.3
4DC-5.2	5	26.84	45039.3
4DC-7.2	7	26.84	45039.3
4CC-6.2	6	32.48	45539.3
4CC-9.2	9	32.48	45539.3
4TCS-8.2	8	41.33	46042
4TCS-12.2	12	41.33	46042
4PCS-10.2	10	48.5	46542
4PCS-15.2	15	48.5	46542
4NCS-12.2	12	56.25	47042
4NCS-20.2	20	56.25	47042
4H-15.2	15	73.6	47055
4H-25.2	25	73.6	47055
4G-20.2	20	84.5	47555
4G-30.2	30	84.5	47555
6H-25.2	25	110.5	67055
6H-35.2	35	110.5	67055
6G-30.2	30	126.8	67555
6G-40.2	40	126.8	67555
6F-40.2	40	151.6	68255
6F-50.2	50	151.6	68255
S6H-20.2	20	36.8	67055
S6G-25.2	25	42.3	67555
S6F-30.2	30	50.5	68255
